Time-Series Databases: Managing Data That Changes Over Time

Introduction

A time-series database (TSDB) is specialized for storing and querying data points indexed by time — sensor readings, server metrics, application logs, financial tick data, and IoT telemetry. Time-series data has unique characteristics that make traditional databases suboptimal:

• Write-heavy — Millions to billions of data points per day.
• Append-only — Data is rarely updated, almost always appended.
• Time-ordered — Queries always involve a time range.
• Retention-based — Old data is eventually summarized or deleted.
• Downsampled — Older data is stored at lower resolution.

---

Time-Series Data Characteristics

The Data Model

Every time-series data point has:

Component	Example	Description
Timestamp	2026-05-24T14:30:00Z	When the measurement was taken
Value	42.5	The measured value
Metric	cpu_usage	What is being measured
Tags/Labels	host=web01, region=us-east	Metadata for filtering

Metric: cpu_usage{host="web01", region="us-east"}
┌─────────────────────┬───────┐
│ Timestamp           │ Value │
├─────────────────────┼───────┤
│ 2026-05-24T14:30:00 │ 42.5  │
│ 2026-05-24T14:30:01 │ 43.2  │
│ 2026-05-24T14:30:02 │ 41.8  │
│ ...                 │ ...   │
└─────────────────────┴───────┘

---

Time-Series vs. Traditional Databases

Operation	PostgreSQL	TimescaleDB (PostgreSQL + TS)	InfluxDB (TSDB)
Write throughput	10K rows/sec	100K-1M rows/sec	1M+ rows/sec
Query: 1 hour avg by 5 min	Minutes (full scan)	Seconds (continuous aggregate)	Seconds
Storage	Row-oriented	Hybrid row/column	Column-oriented
Compression	None by default	90%+ (native compression)	90%+
Retention policies	Manual partition management	Automatic	Automatic
Data downsampling	Manual queries	Continuous aggregates	Downsampling queries
SQL support	Full	Full (SQL)	Limited (Flux/SQL)

---

Time-Series Database Comparison

Feature	TimescaleDB	InfluxDB	Prometheus	VictoriaMetrics	QuestDB
Engine	PostgreSQL extension	Custom TS engine	Custom pull-based	Custom TS engine	Columnar
Query language	SQL	SQL/Flux	PromQL	PromQL compatible	SQL + Influx
Ingestion rate	1M+/sec	1M+/sec	500K/sec	1M+/sec	2M+/sec
Compression	90-97%	90+%	None	90+%	90+%
Clustering	Multi-node (timescaledb)	Enterprise	Native sharding	Native	None
Retention	Automatic with policies	Automatic	Configurable	Configurable	Manual
Continuous aggregates	Yes (native)	No (separate task)	Recording rules	Recording rules	No
Best for	SQL users, operational data	IoT, DevOps	Kubernetes, Cloud Native	High-scale metrics	Financial, high-speed

---

InfluxDB: The Dedicated TSDB

Data Model

# InfluxDB v3 — data model
from influxdb_client import InfluxDBClient, Point
from influxdb_client.client.write_api import SYNCHRONOUS

client = InfluxDBClient(url="http://localhost:8086", token="my-token")
write_api = client.write_api(write_options=SYNCHRONOUS)

# A point = measurement + tags + fields + timestamp
point = (
    Point("temperature")
    .tag("sensor", "sensor-001")
    .tag("location", "warehouse-a")
    .field("value", 23.5)
    .field("humidity", 65.2)
    .time(datetime.utcnow())
)

write_api.write(bucket="sensors", record=point)

Querying

-- InfluxDB SQL (v3)
SELECT time, value
FROM temperature
WHERE sensor = 'sensor-001'
  AND time >= NOW() - INTERVAL '1 hour'
ORDER BY time DESC;

-- Aggregation with downsampling
SELECT time_bucket(INTERVAL '5 minutes', time) as bucket,
       AVG(value) as avg_temp,
       MAX(value) as max_temp,
       MIN(value) as min_temp
FROM temperature
WHERE location = 'warehouse-a'
  AND time >= NOW() - INTERVAL '24 hours'
GROUP BY bucket
ORDER BY bucket;

Retention Policies

-- InfluxDB: automatic data lifecycle
CREATE RETENTION POLICY "one_hour"
ON "sensors"
DURATION 1h
REPLICATION 1
DEFAULT;

CREATE RETENTION POLICY "one_week"
ON "sensors"
DURATION 168h
REPLICATION 1;

-- Create downsample task
CREATE TASK "downsample_1h" ON "sensors"
  EVERY 1 HOUR
  BEGIN
    -- Aggregate 1-minute data to 1-hour averages
    SELECT time_bucket(INTERVAL '1 hour', time) as time,
           AVG(value) as value
    INTO "one_week"."temperature_hourly"
    FROM "one_hour"."temperature"
    WHERE time >= NOW() - INTERVAL '2 hours'
    GROUP BY 1, sensor, location;
  END;

---

Prometheus: Cloud-Native Monitoring

Architecture (Pull Model)

┌─────────────────────────────────────────────────┐
│              Prometheus Server                   │
│  ┌──────────┐  ┌──────────┐  ┌───────────────┐  │
│  │ Retrieval│  │ TSDB     │  │ Alertmanager  │  │
│  │ (pull)   │──│ (storage)│──│ (alerts)      │  │
│  └─────┬────┘  └──────────┘  └───────────────┘  │
│        │                                          │
└────────┼──────────────────────────────────────────┘
         │
    ┌────┼────────────┬──────────────┐
    ▼    ▼            ▼              ▼
  App  App   Node Exporter   Custom Exporter

PromQL (Prometheus Query Language)

# Basic queries
cpu_usage{host="web01"}
http_requests_total[5m]

# Rate (per-second average)
rate(http_requests_total[5m])

# Aggregation
avg by (host) (cpu_usage)

# Histogram quantile
histogram_quantile(0.95, rate(http_request_duration_seconds_bucket[5m]))

# Predict linear regression
predict_linear(node_disk_free_bytes[1h], 3600) < 0

# Recording rule (pre-computed)
- record: job:http_requests:rate5m
  expr: rate(http_requests_total[5m])

Service Discovery and Targets

# prometheus.yml
scrape_configs:
  - job_name: 'kubernetes-nodes'
    kubernetes_sd_configs:
      - role: node
    relabel_configs:
      - source_labels: [__meta_kubernetes_node_label_kubernetes_io_role]
        regex: control-plane
        action: drop

  - job_name: 'custom-app'
    static_configs:
      - targets: ['app01:8080', 'app02:8080', 'app03:8080']

---

TimescaleDB: PostgreSQL for Time Series

TimescaleDB is an extension to PostgreSQL that adds time-series capabilities while retaining full SQL compatibility.

Hypertables

-- Create a hypertable (automatically partitions by time)
CREATE TABLE temperature (
    time TIMESTAMPTZ NOT NULL,
    sensor_id INTEGER,
    location TEXT,
    value DOUBLE PRECISION,
    humidity DOUBLE PRECISION
);

-- Convert to hypertable (partitions by 1 day chunks)
SELECT create_hypertable('temperature', 'time',
    chunk_time_interval => INTERVAL '1 day');

-- Add partitioning by location (optional, for multi-node)
SELECT add_dimension('temperature', 'location', number_partitions => 4);

Compression

-- Enable compression on hypertable
ALTER TABLE temperature SET (
    timescaledb.compress,
    timescaledb.compress_segmentby = 'sensor_id',
    timescaledb.compress_orderby = 'time DESC'
);

-- Compression policy: compress data older than 7 days
SELECT add_compression_policy('temperature', INTERVAL '7 days');

-- Compression ratio: 90-97%
-- 100GB of raw data → 3-10GB compressed

Continuous Aggregates (Materialized Views)

-- Create 5-minute aggregates (refreshed every minute)
CREATE MATERIALIZED VIEW temperature_hourly
WITH (timescaledb.continuous) AS
SELECT time_bucket('5 minutes', time) as bucket,
       sensor_id,
       AVG(value) as avg_temp,
       MAX(value) as max_temp,
       MIN(value) as min_temp,
       stddev(value) as temp_stddev
FROM temperature
GROUP BY bucket, sensor_id;

-- Refresh policy
SELECT add_continuous_aggregate_policy('temperature_hourly',
    start_offset => INTERVAL '3 days',
    end_offset => INTERVAL '1 hour',
    schedule_interval => INTERVAL '1 minute');

Data Retention

-- Automatic data removal
SELECT add_retention_policy('temperature_raw', INTERVAL '30 days');
SELECT add_retention_policy('temperature_hourly', INTERVAL '1 year');
SELECT add_retention_policy('temperature_daily', INTERVAL '5 years');

---

Query Patterns

Downsampling

-- Raw data: 1m intervals, kept 30 days
-- 5m average: kept 1 year
-- 1h average: kept 5 years

SELECT time_bucket('1 hour', time) as hour,
       AVG(value) as avg_temperature,
       PERCENTILE_CONT(0.95) WITHIN GROUP (ORDER BY value) as p95
FROM temperature
WHERE time >= NOW() - INTERVAL '7 days'
GROUP BY hour
ORDER BY hour;

Interpolation (Filling Gaps)

-- Fill missing data with linear interpolation
SELECT time_bucket('5 minutes', time) as bucket,
       INTERPOLATE(AVG(value)) as temperature
FROM temperature
WHERE sensor_id = 1
  AND time >= NOW() - INTERVAL '1 hour'
GROUP BY bucket
ORDER BY bucket;

-- Or use LAST observation carried forward (LOCF)
SELECT time_bucket('5 minutes', time) as bucket,
       LOCF(AVG(value)) as temperature
FROM temperature
GROUP BY bucket
ORDER BY bucket;

Anomaly Detection

-- Detect values outside 3 standard deviations
WITH stats AS (
    SELECT AVG(value) as mean,
           stddev(value) as sigma
    FROM temperature
    WHERE time >= NOW() - INTERVAL '24 hours'
)
SELECT time, value,
       (value - mean) / sigma as z_score
FROM temperature, stats
WHERE time >= NOW() - INTERVAL '1 hour'
  AND ABS((value - mean) / sigma) > 3
ORDER BY time;

---

Storage and Compression

How TSDBs Achieve High Compression

Raw data layout (row-oriented):
time, sensor_id, location, value
14:30:00, 1, "room_a", 23.5
14:30:01, 1, "room_a", 23.6
14:30:02, 1, "room_a", 23.4
14:30:03, 1, "room_a", 23.7

Column-oriented + Delta encoding:
time:    14:30:00, +1s, +1s, +1s  → 1 value + 3 deltas
sensor_id: 1, 1, 1, 1 → run-length encoding: "1 × 4"
location: "room_a" × 4 → run-length encoding: "room_a × 4"
value: 23.5, +0.1, -0.2, +0.3 → delta encoding

Result: ~95% compression vs. raw text

Compression Ratios

Database	Raw	Compressed	Ratio
TimescaleDB	100 GB	3-10 GB	90-97%
InfluxDB	100 GB	5-15 GB	85-95%
Prometheus	100 GB	20-25 GB	75-80%
VictoriaMetrics	100 GB	3-8 GB	92-97%

---

Use Cases

1. Infrastructure Monitoring

# Node exporter metrics collected every 15 seconds
metrics:
  - cpu_usage{host="web01", cpu="0"}
  - memory_used{host="web01", type="RAM"}
  - disk_io{host="web01", device="sda", type="read_bytes"}
  - network_bytes{host="web01", interface="eth0", direction="in"}
  - load_average{host="web01", duration="1m"}

storage:
  raw: 15s intervals, 7 days
  aggregated: 5m intervals, 30 days
  daily: 1h intervals, 1 year

2. IoT Sensor Data

# Millions of devices sending data every minute
from timescaledb import hypertable

sensors = hypertable('sensor_data', 'time',
    chunk_time='1 day',
    compression='7 days',
    retention='90 days'
)

# Query: average temperature per device per hour
query = """
    SELECT time_bucket('1 hour', time) as hour,
           device_id,
           AVG(temperature) as avg_temp,
           COUNT(*) as samples
    FROM sensor_data
    WHERE time >= NOW() - INTERVAL '24 hours'
    GROUP BY hour, device_id
"""

3. Financial Tick Data

-- Stock price ticks: 10M+ per day per instrument
CREATE TABLE ticks (
    time TIMESTAMPTZ NOT NULL,
    symbol TEXT NOT NULL,
    price DOUBLE PRECISION,
    volume BIGINT,
    bid DOUBLE PRECISION,
    ask DOUBLE PRECISION
);

SELECT create_hypertable('ticks', 'time',
    chunk_time_interval => INTERVAL '1 hour');

-- OHLC (Open-High-Low-Close) candlestick query
SELECT time_bucket('5 minutes', time) as bucket,
       symbol,
       FIRST(price, time) as open,
       MAX(price) as high,
       MIN(price) as low,
       LAST(price, time) as close,
       SUM(volume) as volume
FROM ticks
WHERE symbol = 'AAPL'
  AND time >= NOW() - INTERVAL '1 day'
GROUP BY bucket, symbol;

---

Best Practices

Schema Design

-- Good schema: separate metrics by table
CREATE TABLE cpu_usage (time TIMESTAMPTZ, host TEXT, value DOUBLE PRECISION);
CREATE TABLE memory_usage (time TIMESTAMPTZ, host TEXT, value DOUBLE PRECISION);

-- Avoid: single wide table with all metrics as columns
-- (leads to sparse data, poor compression)

Chunk Size Tuning

-- Too small: too many partitions, slow queries
-- Too large: poor memory management, slow ingestion
-- Rule of thumb: each chunk should be 1-10GB compressed

-- For 1000 writes/sec, 1KB each = 86GB/day
-- 1 day chunks = 86GB (too large)
-- 6 hour chunks = 21GB (good)
SELECT set_chunk_time_interval('temperature', INTERVAL '6 hours');

---

Conclusion

Time-series databases are purpose-built for the data that modern systems produce most of: time-stamped measurements from applications, infrastructure, IoT devices, and financial markets.

Use Case	Recommended Database
Infrastructure monitoring (Kubernetes)	Prometheus + VictoriaMetrics
IoT sensor data with SQL queries	TimescaleDB
Real-time analytics, DevOps	InfluxDB
High-frequency financial data	QuestDB
Cloud-native, pull-based metrics	Prometheus

Key takeaways:

1. TSDBs are write-optimized — handle 1M+ data points per second on a single node.
2. High compression (90%+) — store more data for less cost.
3. Automatic data lifecycle — retention policies + downsampling reduce storage costs.
4. SQL support where possible — TimescaleDB provides full SQL compatibility.
5. Different tools for different needs — Prometheus for cloud-native, InfluxDB for DevOps, TimescaleDB for SQL power users.

The right time-series architecture ingests data efficiently, ages it gracefully, and queries it instantly — turning raw timestamped numbers into actionable insights.
