Data Engineering and Big Data

Introduction

Data engineering is the practice of designing, building, and maintaining systems that collect, store, process, and analyze data at scale. While data scientists focus on extracting insights, data engineers build the reliable, scalable infrastructure that makes those insights possible.

In 2026, data engineers are the backbone of data-driven organizations. They build the pipelines that power machine learning models, business intelligence dashboards, real-time analytics, and operational reporting.

---

The Data Engineering Pipeline

End-to-End Architecture

┌─────────┐   ┌──────────┐   ┌──────────┐   ┌─────────────┐   ┌─────────┐
│  Data   │   │  Data    │   │  Data    │   │  Data       │   │  Data   │
│ Sources │──▶│ Ingest   │──▶│ Storage  │──▶│ Transform   │──▶│ Serving │
├─────────┤   ├──────────┤   ├──────────┤   ├─────────────┤   ├─────────┤
│ Apps    │   │ Kafka    │   │ Data Lake│   │ dbt, Spark  │   │ BI      │
│ DBs     │   │ Kinesis  │   │ Warehouse│   │ Airflow     │   │ ML      │
│ APIs    │   │ Airbyte  │   │ Lakehouse│   │ Flink       │   │ Reverse │
│ Logs    │   │ Fivetran │   │          │   │             │   │ ETL     │
│ IoT     │   │ Pub/Sub  │   │          │   │             │   │ API     │
└─────────┘   └──────────┘   └──────────┘   └─────────────┘   └─────────┘

---

1. Data Ingestion

Batch Ingestion

Load data on a schedule (hourly, daily):

# Airflow DAG — Daily ETL
dag_id: daily_orders_import
schedule: "0 2 * * *"  # Daily at 2 AM
tasks:
  - extract_from_postgres:
      sql: >
        COPY orders TO '/tmp/orders_export.csv'
        WITH (FORMAT CSV, HEADER true)
        WHERE created_at >= CURRENT_DATE - 1

  - load_to_s3:
      source: /tmp/orders_export.csv
      destination: s3://data-lake/raw/orders/{{ ds }}/

  - load_to_snowflake:
      table: staging.orders
      file: s3://data-lake/raw/orders/{{ ds }}/*
      warehouse: etl_wh

Stream Ingestion

Process data in real time:

# Kafka producer — Sending order events
from kafka import KafkaProducer
import json

producer = KafkaProducer(
    bootstrap_servers=['kafka:9092'],
    value_serializer=lambda v: json.dumps(v).encode('utf-8'),
    acks='all'
)

def on_order_placed(order):
    future = producer.send('orders', order)
    future.get(timeout=10)  # Wait for acknowledgment
    print(f"Order {order['id']} sent")

# Kafka consumer — Processing stream
from kafka import KafkaConsumer

consumer = KafkaConsumer(
    'orders',
    bootstrap_servers=['kafka:9092'],
    group_id='order-processors',
    auto_offset_reset='earliest',
    enable_auto_commit=False
)

for message in consumer:
    order = json.loads(message.value)
    process_order(order)
    consumer.commit()  # Manual commit for reliability

Ingestion Tools

Tool	Type	Best For
Apache Kafka	Stream	High-throughput, event streaming
Apache Airbyte	ELT	Open-source, 200+ connectors
Fivetran	SaaS ELT	Managed, zero-maintenance connectors
AWS Kinesis	Stream	AWS ecosystem
Google Pub/Sub	Stream	GCP ecosystem
Azure Event Hubs	Stream	Azure ecosystem
Stitch	SaaS ELT	Simple, small to medium data volumes
Debezium	CDC	Database change data capture

---

2. Data Storage

Storage Systems Comparison

System	Best For	Query Type	Schema	Scaling
Data Lake (S3, ADLS, GCS)	Raw data, any format	File-level	Schema-on-read	Infinite
Data Warehouse (Snowflake, BigQuery, Redshift)	Structured analytics	SQL	Schema-on-write	Elastic
Lakehouse (Databricks, Iceberg)	ML + BI	SQL + Spark	Schema evolution	Elastic
NoSQL (DynamoDB, MongoDB, Cassandra)	Low-latency, semi-structured	Key-value, document	Flexible	Horizontal

Choosing the Right Storage

data_storage_strategy:
  # Raw data — never transformed
  raw_layer: s3://data-lake/raw/  (Parquet format)

  # Cleaned and validated data
  staging_layer: s3://data-lake/staging/  (Delta Lake)

  # Business-ready, modeled data
  curated_layer: snowflake.prod.*

  # Real-time operational data
  operational: dynamodb-transactions

  # ML features
  feature_store: feast-feature-store

  # Data sharing
  analytics: looker-explores

The Modern Data Stack

┌─────────────────────────────────────────────┐
│              Data Sources                    │
│  Postgres  │  Shopify  │  Stripe  │  GA4    │
└──────┬──────────┬──────────┬────────┬───────┘
       │          │          │        │
       ▼          ▼          ▼        ▼
┌─────────────────────────────────────────────┐
│           Ingestion (Fivetran / Airbyte)     │
├─────────────────────────────────────────────┤
│         Storage (Snowflake / BigQuery)       │
├─────────────────────────────────────────────┤
│         Transformation (dbt)                 │
├─────────────────────────────────────────────┤
│         BI (Looker / Metabase)               │
├─────────────────────────────────────────────┤
│         Reverse ETL (Hightouch / Census)    │
└─────────────────────────────────────────────┘

---

3. Data Transformation

ETL vs. ELT

Aspect	ETL (Traditional)	ELT (Modern)
Order	Extract → Transform → Load	Extract → Load → Transform
Compute location	Separate ETL server	Data warehouse/lake
Schema	Transform before loading	Transform after loading
Flexibility	Hard to change transformations	Easy to iterate
Storage	Structured only	Raw data available
Tools	Informatica, Talend	dbt, Spark, SQL

dbt (Data Build Tool)

dbt is the industry standard for SQL-based transformations in the modern data stack:

-- models/staging/stg_orders.sql
-- Stage raw orders data
with source as (
    select * from {{ source('shopify', 'orders') }}
),

renamed as (
    select
        id as order_id,
        created_at,
        customer_id,
        total_price::decimal(10,2) as total_amount,
        financial_status,
        fulfillment_status,
        currency
    from source
    where _fivetran_deleted = false  -- Handle soft deletes
)

select * from renamed

-- models/marts/order_summary.sql
-- Business-ready order metrics
with orders as (
    select * from {{ ref('stg_orders') }}
),

customer_totals as (
    select
        customer_id,
        count(*) as total_orders,
        sum(total_amount) as lifetime_value,
        min(created_at) as first_order_date,
        max(created_at) as most_recent_order_date,
        datediff('month', min(created_at), current_date) as customer_tenure_months
    from orders
    group by 1
)

select
    *,
    lifetime_value / nullif(customer_tenure_months, 0) as avg_monthly_value,
    case
        when total_orders = 1 then 'new'
        when total_orders between 2 and 5 then 'regular'
        when total_orders > 5 then 'loyal'
    end as customer_segment
from customer_totals

# dbt_project.yml
name: ecommerce_analytics
version: 1.0
profile: snowflake

models:
  ecommerce_analytics:
    staging:
      +materialized: view
      +schema: staging
    marts:
      +materialized: table
      +schema: analytics
      +incremental_strategy: merge
      +unique_key: order_id

Data Quality Tests (dbt)

# schema.yml — Data quality tests
version: 2
models:
  - name: stg_orders
    columns:
      - name: order_id
        tests:
          - unique
          - not_null
      - name: total_amount
        tests:
          - not_null
          - dbt_utils.accepted_range:
              min_value: 0
              max_value: 1000000
      - name: financial_status
        tests:
          - accepted_values:
              values:
                - pending
                - authorized
                - paid
                - refunded
                - cancelled

  - name: order_summary
    tests:
      - dbt_utils.expression_is_true:
          expression: "total_orders >= 1"

    columns:
      - name: customer_id
        tests:
          - relationships:
              to: ref('stg_customers')
              field: customer_id

---

4. Workflow Orchestration

Orchestration tools manage dependencies and scheduling:

Apache Airflow

# dags/data_pipeline.py
from airflow import DAG
from airflow.operators.python import PythonOperator
from airflow.providers.snowflake.operators.snowflake import SnowflakeOperator
from datetime import datetime, timedelta

default_args = {
    'owner': 'data_engineering',
    'depends_on_past': False,
    'retries': 2,
    'retry_delay': timedelta(minutes=5),
}

with DAG(
    'daily_data_pipeline',
    default_args=default_args,
    description='Main ETL pipeline for analytics',
    schedule_interval='0 6 * * *',  # 6 AM daily
    start_date=datetime(2024, 1, 1),
    catchup=False,
    tags=['production']
) as dag:

    # Task 1: Extract from source databases
    extract_orders = PythonOperator(
        task_id='extract_orders',
        python_callable=extract_from_postgres,
    )

    # Task 2: Load to staging
    load_raw_orders = SnowflakeOperator(
        task_id='load_raw_orders',
        sql='COPY INTO raw.orders FROM @s3_stage',
    )

    # Task 3: Transform with dbt
    run_dbt_transform = BashOperator(
        task_id='run_dbt',
        bash_command='cd /app/dbt && dbt run --models marts',
    )

    # Task 4: Data quality checks
    run_tests = BashOperator(
        task_id='run_tests',
        bash_command='cd /app/dbt && dbt test',
    )

    # Dependencies
    extract_orders >> load_raw_orders >> run_dbt_transform >> run_tests

Data Pipeline Monitoring

# Data freshness monitoring
def check_freshness(table: str, max_hours: int):
    query = f"""
        SELECT MAX(loaded_at) as last_updated
        FROM monitoring.table_metadata
        WHERE table_name = '{table}'
    """
    result = run_query(query)
    hours_since_update = (datetime.now() - result['last_updated']).total_seconds() / 3600

    if hours_since_update > max_hours:
        alert_pagerduty(f"DATA FRESHNESS: {table} is {hours_since_update:.1f}h stale")

---

5. Data Serving

BI Tools

Tool	Type	Best For
Looker	SaaS	Large enterprises, LookML modeling layer
Tableau	Desktop/SaaS	Visual analytics, self-service
Power BI	Microsoft ecosystem	Office 365 integration
Metabase	Open-source	Self-hosted, simple analytics
Superset	Open-source	Cloud-native, Python

Reverse ETL

Send transformed data back to operational systems:

# Census reverse ETL configuration
syncs:
  - name: customer_segments_to_hubspot
    source: snowflake.analytics.customer_segments
    destination: hubspot
    mapping:
      - source_column: email
        destination_field: email
      - source_column: customer_segment
        destination_field: lifecycle_stage
      - source_column: lifetime_value
        destination_field: hsf_calculated_amount
    schedule: every 6 hours

Feature Store for ML

# Feast feature store — Define features
from datetime import timedelta
from feast import FeatureView, Entity, Field
from feast.types import Float32, Int32

customer = Entity(
    name='customer_id',
    value_type=Int32,
    description='Customer identifier'
)

customer_features = FeatureView(
    name='customer_features',
    entities=['customer_id'],
    ttl=timedelta(days=90),
    schema=[
        Field(name='total_orders', dtype=Int32),
        Field(name='lifetime_value', dtype=Float32),
        Field(name='avg_order_value', dtype=Float32),
        Field(name='days_since_last_order', dtype=Int32),
        Field(name='churn_risk_score', dtype=Float32),
    ],
    source=BigQuerySource(
        query="SELECT * FROM analytics.customer_features",
    ),
)

---

Big Data Processing

Apache Spark

from pyspark.sql import SparkSession
from pyspark.sql.functions import *

spark = SparkSession.builder \
    .appName("CustomerAnalytics") \
    .config("spark.sql.adaptive.enabled", "true") \
    .getOrCreate()

# Read from data lake
df = spark.read.parquet("s3://data-lake/raw/orders/*/*.parquet")

# Transform
aggregated = df \
    .filter(col("created_at") >= "2024-01-01") \
    .groupBy("customer_id") \
    .agg(
        count("order_id").alias("total_orders"),
        sum("total_amount").alias("lifetime_value"),
        avg("total_amount").alias("avg_order_value"),
        max("created_at").alias("last_order_date")
    ) \
    .withColumn("segment",
        when(col("total_orders") >= 10, "VIP")
        .when(col("total_orders") >= 3, "Regular")
        .otherwise("New")
    )

# Write to warehouse
aggregated.write \
    .mode("overwrite") \
    .format("delta") \
    .save("s3://data-lake/curated/customer_segments/")

Batch vs. Stream Processing

Aspect	Batch	Streaming
Latency	Minutes to hours	Sub-second to minutes
Data volume	Terabytes+ per run	Continuous, unbounded
Processing	Finite datasets	Infinite streams
State	Stateless per batch	Stateful (windowing, joins)
Complexity	Lower	Higher (exactly-once, watermarks)
Cost	Lower (can burst)	Higher (always running)
Fault tolerance	Re-run failed batch	Checkpointing, state snapshots
Use cases	Daily reporting	Real-time dashboards, alerts

---

Data Governance

Data Catalog

# DataHub metadata
entities:
  - name: orders
    description: Customer order transactions
    ownership:
      - owner: data-engineering@company.com
        type: TECHNICAL_OWNER
      - owner: analytics@company.com
        type: BUSINESS_OWNER
    tags:
      - pii: false
      - classification: internal
      - sla: 99.9% uptime
    schema:
      - column: email
        type: string
        description: Customer email
        tags: [pii, sensitive]

Data Lineage

Track how data flows from source to dashboard:

orders (Postgres)
  └─► stg_orders (dbt view)
       └─► order_summary (dbt table)
            └─► customer_360 (dbt table)
                 ├─► customer_segments (feature store)
                 └─► revenue_dashboard (Looker)

---

Data Engineering Skills

Skill Area	Technologies
Programming	Python, SQL, Java/Scala
Orchestration	Airflow, Dagster, Prefect
Stream Processing	Kafka, Flink, Spark Streaming
Data Warehousing	Snowflake, BigQuery, Redshift
Data Lakes	S3, Delta Lake, Iceberg
Transformation	dbt, Spark
Infrastructure	Docker, Kubernetes, Terraform
Monitoring	Prometheus, Grafana, Datadog
Data Quality	Great Expectations, dbt tests
CI/CD	GitHub Actions, GitLab CI

---

Conclusion

Data engineering is the foundation of the data-driven organization. Key principles:

1. Reliability first — Pipelines must recover from failures automatically.
2. Data quality is everyone's responsibility — Test early, test often.
3. Choose the right tool — Batch for historical analysis, streaming for real-time.
4. Modernize incrementally — Adopt the modern data stack one component at a time.
5. Document everything — Data catalogs, lineage, and ownership are essential at scale.

The best data engineers build systems that are boring — reliable, predictable, and easy to maintain. Invest in monitoring, testing, and documentation, and your data platform will scale with your organization.
